Mains connections |
85-132 V AC / 176-264 V AC, 47-63 Hz |
Mains fuse |
3.15 A / 250 V AC slow-blow |
Dosing range |
1.0 - 99.9 ml, resolution 0.1 ml |
Dosing accuracy |
1 - 2% (depending on selected tube, calibration e.g.) |
Dosing speed |
5 -80 ml/min (with standard double tube set) |
Variable pause between doses |
0.0 - 9.9 seconds |
Anti Drop |
0 - 90° Auto-reverse angle of pump head |
Display |
Color touchscreen, backlighting for perfect read-off, icons |
Sound pressure level |
<79 dB(A) |
Pollution severity |
II |
Safety class |
IP 64 |
Ambient temperature |
+5°C to 45°C (also during transport) |
Unit support surface |
Sturdy support surface |
Remote control / footswitch (2) |
footswitch contacts are designed as normally open contacts (NO) |
Interface RS232 |
RS 232 (host and printer) |
Interface RS 485 (option) |
RS 485 Bio Link (lab. instruments) |
