Size / Width |
|
4-foot |
6-foot |
Dimensions |
Exterior dimensions W x H x D |
mm/in |
1300 x 1568 x 800 / 51.2 x 61.8 x 31.5 |
1900 x 1568 x 800 / 74.8 x 61.8 x 31.5 |
Interior dimensions W x H x D |
mm/in |
1200 x 780 x 630 / 47.2 x 30.7 x 24.8 |
1800 x 780 x 630 / 70.9 x 30.7 x 24.8 |
Shipping dimensions W x H x D |
mm/in |
1410 x 1730 x 925 / 55.5 x 68.1 x 36.4 |
2010 x 1730 x 925 / 79.1 x 68.1 x 36.4 |
Working height of front window |
mm/in |
250 / 10 |
250 / 10 |
Maximum opening height of front window |
mm/in |
535 / 21 |
535 / 21 |
Weight |
Net weight |
kg/lbs |
200 / 441 |
280 / 617 |
Shipping weight |
kg/lbs |
225 / 496 |
315 / 694 |
Electrical data |
Voltage |
V |
230 |
Frequency |
Hz |
50 / 60 |
Filter specification |
H14 HEPA EN 1822, 99.995% @ MPPS, 99.999% at @ 0.3 µm |
Certification |
NSF/ANSI 49, UL, CE |
Ergonomics |
Lighting power |
W |
20 |
40 |
Average illumination |
Lx |
800 (SST) 900 (SmartCoat) |
950 (SST) 1050 (SmartCoat) |
SmartPort access |
Two 3” plugged cable ports, one on each side wall |
Receptacles |
Two standard single receptacles, located on rear wall, right and left sides |
Service valves |
Up to 6 total (3 on each side wall) |
10-inch front opening |
Sound pressure level |
dB (A) |
<63 |
<65 |
Energy consumption, operating set point |
W |
200 |
400 |
Energy consumption, night set-back mode |
W |
70 |
120 |
Heat output, operating mode (non-vented) |
BTU/hr (W) |
683 (200) |
1366 (400) |
Heat output, night set-back mode (lights off, non-vented) |
BTU/hr (W) |
239 (70) |
410 (120) |
Exhaust/inflow air volume |
cfm (m³/h) |
344 (585) |
517 (878) |
Exhaust volume, thimble ducted |
cfm (m³/h) |
448 (761) |
672 (1141) |
